Polysulfone(PSU) material datasheet


LORRIC Taiwan plays a key role worldwide in the manufacturing and supplying of facilities and equipment. Being Taiwan’s primary supplier of nozzles in the domestic market gives LORRIC a strong background to excel on a global scale.


LORRIC Taiwan plays a key role worldwide in the manufacturing and supplying of facilities and equipment. Being Taiwan’s primary supplier of nozzles in the domestic market gives LORRIC a strong background to excel on a global scale.

Polysulfones are a family of thermoplastic polymers. These polymers are known for their toughness and stability at high temperatures. They contain the subunit aryl-SO2-aryl, the defining feature of which is the sulfone group. Polysulfones were introduced in 1965 by Union Carbide. Due to the high cost of raw materials and processing, polysulfones are used in specialty applications and often are a superior replacement for polycarbonates.



Chemical and physical properties

These polymers are rigid, high-strength, and transparent, retaining these properties between −100 °C and 150 °C. It has very high dimensional stability; the size change when exposed to boiling water or 150 °C air or steam generally falls below 0.1%. Its glass transition temperature is 185 °C.


Polysulfone is highly resistant to mineral acids, alkali, and electrolytes, in pH ranging from 2 to 13. It is resistant to oxidizing agents, therefore it can be cleaned by bleaches. It is also resistant to surfactants and hydrocarbon oils. It is not resistant to low-polar organic solvents (e.g. ketones and chlorinated hydrocarbons) and aromatic hydrocarbons. Mechanically, polysulfone has high compaction resistance, recommending its use under high pressures. It is also stable in aqueous acids and bases and many non-polar solvents; however, it is soluble in dichloromethane and methylpyrrolidone.



Polyethersulfone (PES) is a similar polymer with low protein retention.



* Citing source: Wikipedia





Chemical resistance chart

How to use this chart

» Meaning of symbol:

       OK: Recommend

△: Must confirm if usable by testing advanced.

 X: Not recommend

» This chart only provide result of single chemical to material, if client use more than one kinds of chemical in the same time, please choose material by experience.

» This chart is for reference which not able to be applicable to all environment. Please design equipment according to practical experience.



Catagory Chemical PSU
Organic acids Acetic acid △ (20%)
Acetic anhydride
Citric acid OK (40%)
Organic compound  Acetaldehyde OK (<150°C)
 Acetone OK (5%) X (100%)
Alcohol:methyl
X
Aniline
OK
Benzaldehyde

Benzyl alcohol

Benzyl chloride
 △
Corn oil
OK
Ethanol
OK
Ethylene glycol
OK
Fatty acid
OK
Formic acid
OK
Hexane
OK
Lactic acid

Methanol

 Phenol X
Propane,liq
OK
 Propanol
Stearic acid
OK
Inorganic compound  Ammonium chloride
OK
Ammonium hydroxide
OK
Ammonium nitrate
OK
Ammonium sulfate
OK
Aqua regia
OK
Barium chloride
OK
Barium hydroxide
OK
Brine
OK
Calcium Chloride
OK
Calcium hydroxide
OK
Carbonic acid
OK
Chloric acid

Chlorine
Detergent
 OK
Hydrobromic acid

OK (37% @ <150°C)

Hydrochloric acid OK (30%)
Hydrofluoric acid  △ (50%)
Hydrogen peroxide
△ (30%)
Nitric acid
OK (5%) OK (40%) △ (71%)
Phosphoric acid
OK (40%)
Potassium hydroxide
OK (35%)
Potassium nitrate
OK
Potassium sulfate
OK
Sodium hydroxide
OK (50%)
Sulfuric acid

△ (40%) △ (90%)
