• Length: max. 3,000 mm

• Diameter:

 Outer: Ø 20...260 mm

Inner: Ø 10...180 mm

• SUSTAPEEK MG:

- Color：Black, Blue, Green, Natural, Red, Yellow.

- Medical grade PEEK with high purity, USP VI and ISO 10993 tested on semi-finished product, very good sterilisation, could be long term used under 250ﾟC.

Download technical data sheet: Black  Blue  Green  Natural  Red  Yellow

• SUSTAPEEK CF 30: Carbon reinforced PEEK, very high rigidity and stiffness，good dimensional stability, very good sliding behavior.

     Download technical data sheet

• SUSTAPEEK ESD 60 nano: Electrically conductive, very good chemical resistance, suitable for clean room and semi conductor industry, electrical industry, and the environment where have to be prevented static electricity.

     Download technical data sheet

• SUSTAPEEK FG: Food grade PEEK，Suitable for contact with foodstuffs according to (EC) No.1935/2004.

      Download technical data sheet: 1   2   3   4

• SUSTAPEEK GF 30: Carbon reinforced PEEK, ，high rigidity at good dimentional stability, very low creep tendency, suitable for aviation industry, electrical industry, chemical engineering and tank building.

• SUSTAPEEK GLD 140 FG: The color is natural or blue. Food grad PEEK, Suitable for contact with foodstuffs according to (EC) No.1935/2004, excellent dimensional stability, very good sliding behavior, especially suitable for food processing industry.

     Download technical data sheet: 1   2   3   4

• SUSTAPEEK GLD 140: The color is natural or blue.，excellent dimensional stability, very good sliding behavior, high temperature resistance, suitable for mechanical engineering and food processing industry.

     Download technical data sheet: 1   2   3   4

• SUSTAPEEK MOD: Graphite, ptfe, and carbone fiber added PEEK, very good sliding behavior, rigidity and dimensional stability, very low creep tendencym, radiation resistance, suitable for chemical engineering, electrical industry, mechanical engineering, aviation industry, and medical industry.

     Download technical data sheet

• SUSTAPEEK MOD ESD 90: It is anti-static SUSTAPEEK MOD, very good sliding behavior, rigidity and dimensional stability, very low creep tendencym, radiation resistance, radiation resistance, suitable for chemical engineering, electrical industry, mechanical engineering, aerospace transportation, and medical industry.

     Download technical data sheet

Röchling (Roechling) Engineering Plastics is a leading plastic manufacturer of a broad range of semi-finished basic shapes from Germany. Röchling Engineering Plastics manufactures and sells Polystone® thermoplastic shapes such as Polystone® M UHMW-PE, Polystone® G HDPE and Pipe Grade HDPE, PVC, PEEK, and Polystone® P Polypropylene sheet products. These products are available in MegaSheet which is the largest sheet available anywhere. We can supply these sheets in thickness ranging from 3/8" to 4". They can be used as one huge sheet or cut to achieve an endless variety of sheet sizes. Röchling also manufactures Durostone® CHP fiberglass reinforced materials for soldering operations in printed circuit board assembly.

Röchling Engineering Plastics is the only manufacturer in the U.S. to be ISO 13485:2003 Certified that supplies a broad product offering of engineering plastic stock shapes to the medical market. The ISO 13485:2003 certification represents the requirements for a comprehensive management system for the design and manufacturing of medical devices including:

• Controls to Ensure Product Safety
• Risk Management Activities
• Inspection and Traceability
• Documentation and Validation of Processes
• Verification of the effectiveness of corrective and preventive actions
